PGS-1-100-F
Faw DieselSilent SERIES

FAWDE 6A4DF2-14D

100 KVA diesel generator set with FAWDE engine featuring SMARTGEN digital control, automatic battery charger with two-stage charging, and nano-technology battery safety features. Includes sound proof/weather proof steel enclosure and comprehensive engine protection system.

Standby Power

80 Kw/ 100 Kva

Prime Power

72 Kw/ 90 Kva

Model

PGS-1-100-F

Fuel Type

Diesel

Operation Conditions
Altitude1500m
Temp40°C
Derating1% per 100m above 1500m

Generator Set Data

Standby Power

80 Kw/ 100 Kva

Prime Power

72 Kw/ 90 Kva

Speed

1800rpm

Frequency

60Hz

Starting Voltage

24v

Fuel Capacity

Good for 8 Hours

Connection Mode

Single Phase

Type

Silent

Voltage Options

208v/120v 220v/127v 240v/139v 380v/220v 440v/254v 480v/277v

Dimensions & Weight

L 255 x H 135 x W 105 cm / 900 Kgs

Engine Specifications

cylinders

4 inline

aspiration

Natural aspiration

cycle

4

combustion

Direct Injection

cooling

Water Cooled

bore Stroke

102x118

compression

17:1

displacement

3.86 L

Alternator Specifications

technology

Stamford Technology

insulation

Class H

excitation

Self-Excitation or PMG

protection

Ip23
